Product Description

Product DescriptionAll used shipping container checked by third party and issue report, and we would provide you the actual photo for view before shipped .
Our used shipping container is Valid in Shanghai, Ningbo, Guangzhou, Qingdao.

Specification

1. Product Name: ISO shipping container
2. Place of Product: Shanghai, Ningbo, Guangzhou, Qingdao, China
3. Modes of packing: SOC(shipper own container)
4. External Dimensions (L x W x H)mm: 12192*2438*2896mm
5. Internal Dimensions (L x W x H)mm: 12092*2352*2698mm
6. Door Dimensions (W x H)mm: 2340*2585mm
7. Inner capacity: 76.4 CBM
8. Tare Weight: 3730 KGS
9. Max Gross Weight: 32500 KGS

Maritime Container Material List

1. Corner: ISO standard corner, 178x162x118mm
2. Floor Beam for long side: Steel: CORTEN A, thickness: 4.0mm
3. Floor Beam for short side: Steel: CORTEN A, thickness: 4.5mm
4. Floor: 28mm, intensity: 7260kg
5. Column: Steel: CORTEN A, thickness: 6.0mm
6. Inner column for back side: Steel: SM50YA + channel steel 13x40x12
7. Wall panel-long side: Steel: CORTEN A, thickness: 1.6mm+2.0mm
8. Wall panel-short side: Steel: CORTEN A, thickness: 2.0mm
9. Door Panel: Steel: CORTEN A, thickness: 2.0mm
10. Horizontal beam for door: Steel: CORTEN A, thickness: 3.0mm for standard container and 4.0mm for high cube container
11. Lockset: 4 set container lock bar
12. Top Beam: Steel: CORTEN A, thickness: 4.0mm
13. Top panel: Steel: CORTEN A, thickness: 2.0mm
14. Paint: Inside wall paint thickness: 75µ Outside Wall paint thickness: 30+40+40=110uOutside Roof paint thickness: 30+40+50=120u Chassis paint thickness: 30+200=230u

More uses

Packing&Shipping

Transport and ship with SOC style overworld. (SOC: Shipper own container)
