Products Description
- Container frame :
ISO 20’GP/HQ container, new. CIMC container, pre-cutting, and welding before painting under customized design. No ending door default.
Material: Corten A steel - Container Wall and Roof : Material: Corten A steel
- Hatch: Pre-design a hatch plate for possible supplier gas, wifi, electrical power, plumbing pipe
Size: 350*350mm default
default Q’ty: 1 set - Container floor:
ISO maritime plywood floor
Plywood thickness: 28 mm
Plywood moisture content: Less than 14 %
Plywood ply number: Min. 19 plies
Plywood material: Apitong, Hardwood, Bamboo, OSB - container paint :
Inside wall paint thickness: 75µ, default RAL7035.
Outside Wall paint thickness: 30+40+40=110µ
Outside Roof paint thickness: 30+40+50=120µ
Chassis paint thickness: 30+200=230µ
Painting: white or RAL color. - Hingle System: Hinge system for folding both side floor With remote control
- Service Door: special section steel sheet
To cover the route to fix the wires of the hinge system - Pop up window :
gas spring pop-up window.
Size: 2000*1000mm
with 2 pcs gas spring. - Service Door : Size: 700*600mm or per your advice.
- internal wall: container wall. Paint: default RAL 7002.
- Ceiling :
50mm rock wool sandwich panel.
Face: 0.5mm PPGI both side
Insulation: 50mm rock wool
Color: RAL9002 - Floor: 28mm solid timber floor
- Distribute box: per drawing, 1 for light, 1 for the socket, 1 for kitchen, 1 for power. 1 set for an apartment.
- RCD: per drawing- Legrand
- Electrical wire: Electrical wire
- Outlet: Per drawing. Default Brand: Legrand
CE, UL, AZ certification available. - light-Bar area: LED downlight. Brand: PHILIPS or same level.
- Switch: per pic, color: white.
Default Brand: Legrand - Industrial plug: 1pcs Industrial Plug
Inside wall paint thickness: 75µ, default RAL7035.
Outside Wall paint thickness: 30+40+40=110µ
Outside Roof paint thickness: 30+40+50=120µ
Chassis paint thickness: 30+200=230µ
Painting: white or RAL color.
Container Part:
1.Pre-cut the hole of window and door
2.With necessary support system for the cut area
3.Paint under client demand. (pls offer the RAL No.) 4.Special demand from the client, such as logo, brand
Size: 400*400mm (may amend according to design)
Place: per design. Usually on the bottom or top of the container.
Final per design.
Will pre-welding the steel frame of window and door according to the size of each window/ door.
Wide usage of Hysun Modified House
Hysun function modular unit, they can use separately or flexible to be combined together in various fields.
Our Advantages
Hysun Modified Container House
Hysun is always insisted on using new customized containers to convert to your house. They are made of Corten A steel under SGS standard, important, they are ready to cut and welding from your design before painting also the same material and quality as the ISO maritime container.
They are different from the most way in the market to cut a new maritime container then paint(this way also would damage the original paint of maritime container and reduce the life span of the house).
For the materials, we are always insisted on high quality, too.
Hysun Container Frame
New Customized ISO shipping container, new frame, new paint. No second shipping container to modified.
Hysun containers are a longer life span and less maintenance.
Meet CSC standards. Valid to issue CSC certification.
SOC(Shipper Owned Container) to worldwide.
Packing&Delivery
Transport and ship with SOC style.
SOC: Shipper own container
