Product description

Products Description

Hysun modified container is a type of modular product made of ISO shipping container and adds modern decoration to modified to accommodation, commercial, health, storage, and more usage. They are green and flexible, also fashionable.
Hysun modified container also is a turn-key house and ready for use directly.

  1. Container frame: ISO shipping container, new. CIMC container, pre-cutting, and welding before painting under customized design.
    Material: Corten A steel
  2. Container Wall and Roof: Material: Corten A steel
  3. Hatch: Pre-design a hatch plate for possible to supplier gas, wifi, electrical power, plumbing pipe;
    Size: 350*350mm default;
    default Q’ty: 1 set;
  4. Container floor:
    ISO maritime plywood floor
    Plywood thickness: 28 mm
    Plywood moisture content: Less than 14 %
    Plywood ply number: Min. 19 plies
    Plywood material: Apitong, Hardwood, Bamboo, OSB
  5. Wallalternative:
    A- sandwich panel.
    Face: 0.5mm PPGI both side
    Insulation: 50mm rock wool /EPS/ PU etc
    Color: RAL9002
    B-Plaster Board with paint, wallpaper, ceramic tile
  6. Ceiling:
    50mm rock wool sandwich panel.
    Face: 0.5mm PPGI on both side
    Insulation: 50mm rock wool
    Color: RAL9002
  7. Trim: Alu trim for corner between the wall and wall, wall and ceiling
  8. Floor 3 options:
    A-28mm solid timber floor
    B-LG brand vinyl carpet sheet; More pattern on option.
    C-SPC floor
  9. Distribute box: per drawing, 1 for light, 1 for the socket, 1 for kitchen, 1 for power. 1 set for an apartment.
  10. RCD: per drawing- Legrand
  11. Electrical wire: full set- Pre-install into the wall
  12. Outlet: Per drawing. Default Brand: Legrand; CE, UL, AZ certification available.
  13. Switch: per pic, color: white. Default Brand: Legrand
  14. Industrial plug: 1pcs Industrial Plug
productive process
Container Body
Container Part:
1.Pre-cut the hole of window and door
2.With necessary support system for the cut area
3.Paint under client demand. (pls offer the RAL No.) 4.Special demand from the client, such as logo, brand
Container Paint.
Inside wall paint thickness: 75µ, default RAL7035.
Outside Wall paint thickness: 30+40+40=110µ
Outside Roof paint thickness: 30+40+50=120µ
Chassis paint thickness: 30+200=230µ
Painting: white or RAL color.
Window and door frame:
Will pre-welding the steel frame of window and door according to the size of each window/ door.
Hatch for possible passage pipes.
Size: 400*400mm (may amend according to design)
Place: per design. Usually on the bottom or top of the container.
Final per design.

Our Advantages

A little higher space, A more comfortable feeling

Valid in 20GP/20HQ
1. 20GP:
external size: 6055*2438*2590mm
internal size: 5800*2200*2200mm
2. 20HQ:
external size 6055*2438*2896mm
internal size: 5800*2200*2500mm

Hysun Modified Container House
Hysun is always insisted on using new customized containers to convert to your house. They are made of Corten A steel under SGS standard, important, they are ready to cut and welding from your design before painting also the same material and quality as the ISO maritime container.
They are different from the most way in the market to cut a new maritime container then paint(this way also would damage the original paint of maritime container and reduce the life span of the house).
For the materials, we are always insisted on high quality, too.

Hysun Container Frame
New Customized ISO shipping container, new frame, new paint. No second shipping container to modified.
Hysun containers are a longer life span and less maintenance.
Meet CSC standards. Valid to issue CSC certification.
SOC(Shipper Owned Container) to worldwide.

Packing&Delivery

Transport and ship with SOC style.
SOC: Shipper own container
